With the rapid development of science and technology in recent years, a variety of technology industries are also in the rapid development of our country, more and more machinery and equipment broke into our lives. Shantou Mingfa Machinery Co., Ltd. With the social flow, innovation and production technology and production mechanism, to produce a series of high-quality plastic machinery and food machinery, greatly to meet the needs of enterprises and individuals at home and abroad.
These machines have made a considerable change in our lives, such as plastic cups, which allow us to labor on a large scale without any time and effort, and as long as the operator moves his finger at the machine Operation can be; Moreover, through the plastic cup machine produced a one-time plastic cup, lightweight and convenient, cheap and easy to use. Here we introduce the next Ming made the production of plastic cup machine:
& nbsp; & nbsp; & nbsp; a, plastic cup machine structure and principle
The main material is PP, PS, PET, PVC, HIPA, PE, PVC, HIPA, PE, PVC, HIPA, PE, PVC, HIPA, PE, PVC, HIPA, PE Etc., long-term use temperature 0 ~ 70 ℃. Common specifications: upper diameter 68mm, high 74mm, bottom 48mm, wall thickness of 10 silk, 2-10 grams / month.
& nbsp; & nbsp; & nbsp; Second, the plastic cup machine use
Plastic cup machine is mainly used for the production, production of disposable tableware, cold cup, yogurt cup, jelly cup, ice cream cup, fast food box, instant noodles bowl and so on. At the same time can also be processed medicine, light industry, textile, tourism, toys and other related plastic packaging products. One of the products is a plastic cup is used to hold liquid or solid items of plastic products, with a cup of heat, into the hot water does not soften, no cup care, impermeable, colorful, light weight, easy to break Features. Widely used in aviation, office, hotels, bars, KTV, home and other venues.
& nbsp; & nbsp; & nbsp; Third, the characteristics of plastic cup machine
& nbsp; & nbsp; & nbsp; 1. High efficiency, energy saving, safety and environmental protection, high yield of finished products.
& nbsp; & nbsp; & nbsp; 2. Machine set to send film, heating, stretching, forming, trimming one-time completion.
3, machine, electricity, gas integration; with manual, semi-automatic, automatic three kinds of operating functions.
& nbsp; & nbsp; & nbsp; 4. Raw materials to adapt to a wide range. Such as PS, PP, PVC, PET, ABS and other plastic sheet can be processed.
& nbsp; & nbsp; & nbsp; 4, the main technical parameters of plastic cup machine
Maximum Molding Area (mm)
600 × 300
Sheet thickness range (mm)
0.2-2.2
Maximum forming depth (mm)
160
Maximum sheet diameter (mm)
750
Maximum width of sheet (mm)
700
Use air pressure (mpa)
0.7
Minimum width of the sheet (mm)
300
Air consumption (m3 / min)
2
Water consumption (m3 / h)
0.5
Power three-phase four
380V ± 15V
Heating rated power (kw)
38
Main device dimensions (L × W × H) (cm)
315 × 150 × 250
Host rated power (kw)
5.5
Total device weight (T)
3.8
Maximum device speed (p / min)
12-30
Sheet size (L × W × H) (mm)
700 × 700 × 162
Shantou Mingfa Machinery Co., Ltd. not only has various types of cup machine, as well as plastic multi-layer co-extruded sheet machine, automatic plastic thermoforming machine, POF multi-layer co-extrusion heat shrinkage Blown film machine and efficient plastic recycling granulator, and other six series of more than 20 advanced equipment. High technical content, supporting reasonable, energy efficient, easy to operate. Companies follow the "people-oriented, treat people with sincerity, mutual benefit and common development" principle and abide by the "quality of life is the enterprise, the credibility of the development of the guarantee" of the faith, the best-selling products at home and abroad more than 30 countries and regions, reputation. The company has passed ISO9001-2000 version of the international quality system certification, and access to measurement system certification certificate. Users are welcome to purchase machine!
